Want to build a stateful AI workflow in Java instead of hiding everything behind one giant prompt?
Meet LangGraph4j.
🔸 TLDR
LangGraph4j brings graph-based agent orchestration to Java.
Think:
STATE → NODE → DECISION → NODE → ... → END
Instead of letting an LLM control everything, you explicitly model how your AI application can move through its workflow.
🔸 WHAT IS LANGGRAPH4J?
LangGraph4j is a Java library for building stateful, graph-based AI applications and agentic workflows.
You model the application as a graph:
▪️ State → shared data flowing through the workflow
▪️ Nodes → Java code, LLM calls, agents or tools doing the work
▪️ Edges → decide what happens next
▪️ Checkpoints → persist state and resume execution
It is designed to work with both LangChain4j and Spring AI.
Let's build the mental model in 5 steps. 👇
Let's build the mental model in 5 steps. 👇
🔸 1. DEFINE THE STATE
class MyState extends AgentState { static final String QUESTION = "question"; static final String ANSWER = "answer"; MyState(Map<String, Object> init) { super(init); } }
The state is the workflow's shared memory. Each node can read it and return updates that are passed to the following nodes.
🔸 2. CREATE YOUR NODES
var research = node_async(state -> { var question = state.value("question", ""); return Map.of("research", search(question)); });
A node performs one unit of work. It can execute normal Java code, call an LLM, query a database or invoke a tool.
🔸 3. CONNECT THE WORKFLOW
graph.addNode("research", research) .addNode("answer", answer) .addEdge(START, "research") .addEdge("research", "answer") .addEdge("answer", END);
Edges define the execution flow.
And they can be conditional, allowing the current state to determine which node executes next. 🔀
🔸 4. COMPILE THE GRAPH
var app = graph.compile();
Compilation turns your definition into an executable graph and validates its structure before execution.
🔸 5. RUN IT 🚀
var result = app.invoke(
Map.of("question", "What is Project Valhalla?")
);Give the graph its initial state and let it execute the workflow until it reaches END.
You can also stream intermediate states and add checkpoint persistence for long-running workflows.
🔸 LANGCHAIN4J VS LANGGRAPH4J
They overlap, but they solve the problem at different levels.
▪️ LangChain4j is primarily an AI application toolkit: connect to LLMs, manage prompts and memory, call tools, build RAG pipelines and create AI Services. It now also includes its own agentic APIs.
▪️ LangGraph4j focuses on orchestration: model a complex AI workflow explicitly as a graph of states, nodes and edges, with conditional routing, checkpoints, pause/resume and streaming.
A simple way to picture it:
LangChain4j → gives your Java application AI capabilities. 🧠
LangGraph4j → coordinates how those capabilities work together over time. 🕸️
And they are not necessarily competitors.
LangGraph4j is explicitly designed to work with LangChain4j (or Spring AI) inside its graph nodes.
For example:
LangChain4j LLM + Tools + RAG + Memory
LangGraph4j START → Research Agent → Decision → Tool → Review → END
👉 Use LangChain4j when the main challenge is integrating AI capabilities into Java.
👉 Consider LangGraph4j when the main challenge becomes controlling a multi-step, stateful workflow involving those capabilities.
🔸 WHICH KIND OF "GRAPH" ARE WE TALKING ABOUT? 🕸️
The word graph appears in several technologies, but it does not mean the same thing.
▪️ 🔴LangGraph4j → EXECUTION GRAPH
In LangGraph4j, the graph describes how an AI workflow executes.
START
↓
RESEARCH
↓
DECISION
↙ ↘
TOOL ANSWER
↓
END
A node is a computation step: Java code, an LLM call, an agent or a tool.
An edge determines which step can execute next.
👉 The graph represents control flow and state transitions.
▪️ 🟠Neo4j → KNOWLEDGE / DATA GRAPH
Neo4j is a graph database.
Here, nodes represent stored entities and relationships represent how those entities are connected.
(Java) ──USED_BY──> (Spring) │ └──HAS_FEATURE──> (Virtual Threads)
The graph is the data itself.
👉 Neo4j answers questions such as: "How are these things related?"
▪️🟡GraphQL → QUERY LANGUAGE FOR CONNECTED DATA
Despite its name, GraphQL does not store a graph.
It is an API query language that lets clients request exactly the structured and related data they need.
user { posts { comments } }
👉 GraphQL answers: "What data do I want from this API?"
So remember:
▪️ Neo4j → graph of knowledge and relationships 🧠
▪️ GraphQL → query related API data 🔎
▪️ LangGraph4j → graph of execution and decisions 🤖
Same word: graph. Three very different abstractions.
Neo4j stores the graph. GraphQL queries data. LangGraph4j executes the graph.
🔸 LANGGRAPH4J VS EMBABEL
Both build agentic applications on the JVM, but their orchestration philosophy is quite different.
▪️🟢 LangGraph4j → YOU DESIGN THE GRAPH
With LangGraph4j, you explicitly define the workflow:
START
↓
RESEARCH
↓
DECISION
↙ ↘
TOOL ANSWER
↓
END
You define the nodes, edges, state and routing rules.
That gives you strong control over how execution moves through the application, including conditional paths, checkpoints, pause/resume and human-in-the-loop workflows.
Think: "Here is the workflow. Execute it."
▪️ 🔵Embabel → YOU DEFINE THE GOAL
Embabel takes a more goal-oriented approach.
You define things such as:
@Action Research research(Topic topic) { ... } @Action Article write(Research research) { ... } @AchievesGoal Article finishedArticle(...) { ... }
Instead of explicitly wiring every transition, Embabel can determine which actions are needed to reach the goal.
Its planner can dynamically create a sequence of actions and replan after each action when the situation changes.
Think: "Here are the actions available and the goal. Find a way to achieve it."
So the mental model is:
▪️ LangGraph4j → explicit workflow orchestration 🕸️
▪️ Embabel → goal-oriented agent planning 🧠
Or even shorter:
LangGraph4j: you draw the road.
Embabel: you define the destination.
Both can produce sophisticated agentic systems; but LangGraph4j emphasizes explicit control flow, while Embabel emphasizes dynamic planning toward goals.
🔸 TAKEAWAYS
▪️ LangGraph4j is about orchestration, not another LLM.
▪️ Nodes perform work; edges control where execution goes next.
▪️ State travels across the entire workflow.
▪️ Conditional edges enable dynamic agent behavior.
▪️ Checkpoints make long-running and resumable workflows possible.
▪️ It integrates with Spring AI and LangChain4j.
Java AI is moving beyond "send prompt, get answer."
We're starting to build actual workflows. 🕸️🤖☕
